Description:
Technical Specifications:

  • Motor Size: Φ55.6*33.9mm
  • Copper Wire: 220°C high temperature resistance: Level C
  • Stator: Imported silicon steel sheet; Anti-rust treatment; 150°C high temperature-resisting coatings
  • Coil Insulation Test: 500V
  • Configuration: 24N28P
  • Centrifugal Cooling Design: YES
  • Shaft Diameter: IN: 6mm, OUT: 4mm
  • Rotor Dynamic Balance Standard: ≤5Mg
  • Bearing: Imported 696ZZ
  • Motor Dynamic Balance Standard: ≤10Mg
  • Magnet Level: 180°C high temperature resistance
  • IP: IP45
  • Lead Cable: 16AWG*150mm
  • KV: 300
  • Rated Voltage (Lipo): 6-8S
  • Idle Current(15V): 1.1A
  • ESC Recommendation: AIR 40A
  • Peak Current(180s): 40A
  • Propeller Recommendation: 20-22"
  • Max.Power(180s): 1000W
  • Motor Weight (incl. Cable): 170g
  • Internal Resistance: 63mΩ
  • Package Weight: 350g
